Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Brand Name : WELLDONE

Model Number : SZG-(100-6000)

Certification : CE, ISO 9001: 2008, ISO 10004

Place of Origin : China

MOQ : 1Set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10Sets/Months

Delivery Time : 10-40Working Days

Packaging Details : Wooden Case + Plastic Film + Steel Frame

Voltage : 110V/220V/380V/415V/480V

Hertz : 50HZ, 60HZ

Material : SUS304/SUS316L

Installation Power : 1.5KW-55KW

Drying Temperature : 50-150℃

Weight : 0.5Ton-40Ton

Heating Resource : Steam/Thermal Oil/Hot Water

Drying Efficiency : 80%

Way to Control : Button/Touch Screen/Remote

Special Design : Explosion Resistance/Low Temperature Drying

Loading Capcity : 25KGS/Batch-3000KGS/Batch

Contact Now

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Principle of Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

SZG Vacuum Rotary Dryer is a kind of double conical vacuum dryer. Under the vacuum condition, filling the heat medium into dryer jacket, raw material being dried with the contact of dryer chamber. Evaporated moisture is sucked out by vacuum pump. Due to the rotating of dryer body, raw material is moving inside the chamber, which increase the drying speed and uniformity.
The dryer is suitable for powder and granule form raw material with good fluidity.

Features of Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

◆ _The dryer is suitable for drying and mixing powder or granule shape raw material of pharmaceutical industry, foodstuff industry, chemical industry and so on.

◆ _Flammable and explosive material drying should be clamed.

◆ _When use hot water or heat conducting oil as heating resource, should be claimed before the order. Please claimed when order if need certificate of pressure vessel.

◆ _Please claim it when need GMP standard. (It should use direct gear drive, closed construction, vacuum cover is sintered metal mesh).

◆ _Material:SS304/SS316L/SS321/ hastelloy etc, inner wall is enamel for your choice.

◆ _We recommend being adopt speed adjustable control and central axis integrated procession when the volume of machine is larger than 2000L

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Technical Parameters of Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Picture of Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

After Sell Service

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Service before sell:

----Provide relative technical data for help equipment selection

----Running pilot test

----Offering advice for equipment selection, material analysis

----Provide flow chart, basic drawing

----Provide technical design



Service in sell:

----Provide factory layout according to contract

----Manufacturing ordered equipment according to the related standard

---- A presentation report of manufacturing situation will be offered every 15days

---- Tracking and supervising in whole manufacturing and transporting period according to the contract requirement

---- Photo of wooden case will be offered, wooden case with standard shipping marks.

---- Photo of freight loading will be offered.

---- A record of detailed delivery list will be offered

---- A record of detailed freight loading list will be offered

---- All of wooden case will be marked serial number, all of attachments will be marked serial number, convenient for client's clearing



Service after sell:

----Send service engineer for help instruct installation.

----Send service engineer for running test at site and training the operator

----Help client for maintenance and repair

----Provide one year spare part

----Quality warranty for two years after sell

Packing & Delivery

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product

Energy Saving Good Quality Double Conical Vacuum Dryer For Heat Sensitive Product
